UBM-XG

ORION Deployments

Cloud Firewall Solutions

The ORION cloud firewall platforms include an array of threat prevention and application management functions. These platforms are designed to improve an organizations network security, which is to say that the UBM-XG operating system protects an organization from downtime with advanced enterprise class capabilities including AI-based sandboxing and application control. All ORION solutions include automated failover and network redundancy.

UBMXG Spec

Cloud Firewall Solutions
World's best visibility, protection, and response. ZeroOutages cloud firewall solutions offer unsurpassed network security within the most cost effective service in the industry.

Easy Integration and Management
Each UBM appliance includes built-in transparent mode installation and simple web-based configuration and reporting.

Efficient Use Of Secondary Links
Each UBM appliance not only ensures automated failover of network connectivity in the event of an ISP outage, but it also can utilize the backup connection for lower priority traffic, like accelerated web downloads and email connectivity, thus making efficient use of the backup link and speeding up end-user connectivity.

Best Path Routing w/SLA Reporting
Each UBM appliance includes XRoads' adaptive Best Path Routing™ technology which constantly monitors critical remote sites and provides real-time SLA metrics and can update routing tables based on the performance of each WAN link.

Network Reporting
A critical aspect of any traffic shaping appliance is its ability to provide real-time network reporting, as without reporting how does the network administrator know what policies to create. Each UBM appliance includes both caned and custom user-defined reports which are updated in real-time.

Product Specifications

The following is a listing of specifications for the UBM-XG50 series product. The UBM-XG platform is designed to incorporate our full feature set and/or can be licensed to include our full feature set without having to purchase additional hardware. Affordable, Scalable, and Reliable

Feature Value
Ports (1)LAN, (2)WAN links, Console
Ethernet 4 x 10/100/1000 GigE AutoSense
Bypass Yes
Rack Mount / Size Yes / Desktop
Power Full Range 12V, 5A External
Certification FCC CE RoHS
Dimensions 9.05" x 5.98" x 1.73"
Shipping Weight 5lbs
Environmental 0 to 40C (32 to 104F)
ECC Memory Yes DDR3 (2GB)
Network Cache Flash Memory

icon-Speedometer Performance

Feature Value
Physical Interface 1000 Mbps
Sustained Routing Performance1 Up to 200 Mbps
Site2Site Tunnel Support 2
Shaping Policies 256
Filtered Sessions 25/s
Maximum Connections 48,000 Sessions
Throughput rates are based on lab testing with average packet sizes between 512-1024 bytes.

FAQs

Does this appliance include Automated ISP failover?
Yes, this appliance includes deep-path inspection to determine when a link has failed a updates routing on the fly.

Library

XRoads Networks provides this product library to provide quick access to materials about this appliance and its unique capabilities.

All of the files below are in PDF format.
